Tempat asal XIAN, SHANNXI CHINA
Nama merek XIWUER
Sertifikasi ISO9001,ISO14001,OHSAS18001
Nomor model CT8-2-30KV-1000PF
Kuantitas min Order 1 buah
Harga dapat dinegosiasikan
Kemasan rincian Karton
Waktu pengiriman 10-15 hari
Syarat-syarat pembayaran L/c, t/t
Menyediakan kemampuan 4.000.000 buah setahun

Hubungi saya untuk sampel gratis dan kupon.

ada apa:0086 18588475571

Wechat wechat: 0086 18588475571

Skype: sales10@aixton.com

Jika Anda memiliki masalah, kami menyediakan bantuan online 24 jam.

x
Detail produk
Menyoroti

30kV-1000pF High Voltage Doorknob Capacitor

,

30kV-2700pF HV Ceramic Capacitor

,

30kV-12000pF Doorknob Capacitor
Tinggalkan pesan
Deskripsi Produk
High-Voltage Doorknob Capacitors for Advanced Materials Processing

Essential components for plasma cleaning, magnetron sputtering, laser surface modification, and other advanced materials processing applications.

Technical Specifications
No. Specification Dissipation Withstanding Voltage Insulation Resistance Dimensions (mm)
1 20kV-2000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:45 | H:19 | L:23 | D:12 | M:5
2 20kV-10000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:65 | H:15 | L:19 | D:12 | M:5
3 20kV-18000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:80 | H:17 | L:25 | D:12 | M:5
4 30kV-1000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:45 | H:24 | L:32 | D:12 | M:4
5 30kV-2700pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:60 | H:20 | L:28 | D:12 | M:4
6 30kV-12000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:45 | H:19 | L:23 | D:12 | M:5
7 40kV-150pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:74 | H:18 | L:26 | D:12 | M:5
8 40kV-500pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:28 | H:33 | L:41 | D:8 | M:4
9 40kV-7500pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:80 | H:24 | L:29 | D:12 | M:6
10 40kV-10000pF ≤0.0040 1.5Ur● 1min ≥1.0 x 105MΩ D:80 | H:22 | L:26 | D:16 | M:5
Precise Energy Control for Advanced Materials Processing

High-voltage doorknob capacitors serve as critical components in energy regulation and stabilization for:

  • Plasma cleaning systems
  • Magnetron sputtering equipment
  • Laser surface modification tools
Key Power Supply Requirements for Material Processing
  • Extremely stable and low noise: Ensures consistent plasma density, laser energy, and sputtering rates
  • Efficient pulse power capability: Supports high-frequency, high-energy instantaneous pulses
  • Strong load shock resistance: Maintains stability during plasma ignition and fluctuations
Core Functions in High-Voltage Power Systems
  • DC link support and filtering: Smooths high-frequency ripple for clean, stable DC high voltage
  • Pulse energy reservoirs: Stores and releases energy for high-peak power pulses
Our Capacitor Advantages
  • High energy density with rapid charge/discharge capabilities
  • Extremely low equivalent series inductance (ESL) for instantaneous energy delivery
  • Rugged epoxy resin vacuum casting with metal housing for industrial durability
  • Excellent resistance to moisture, dust, and chemical corrosion

Choosing our high-voltage doorknob capacitors ensures precision energy control for your most demanding material processing applications.
